次以及周檢合格率情況，開展扭矩扳手的自校班前檢查工作，保證扭矩扳手的準確性，從而確保緊固件扭矩質量。

To ensure the accuracy of the torque wrench and ensure the quality of the fastener torque.

扭力扳手使用注意事項：

Notes for use of torque wrench:

1、在選擇扭力扳手時，要根據螺栓或螺母的尺寸來選擇合適開口尺寸的扭力扳手。如果扭力扳手的開口尺寸大于螺栓或螺母的尺寸，那在使用時，容易滑脫并損傷螺件的六角。如果扭力扳手的開口尺寸太小，那就無法嵌入到螺栓或螺母中進行扭動。

1. When selecting the torque wrench, the appropriate opening size of the torque wrench should be selected according to the size of the bolt or nut. If the opening size of the torque wrench is larger than the size of the bolt or nut, it is easy to slip off and damage the hexagon of the screw. If the opening size of the torque wrench is too small, it cannot be inserted into the bolt or nut for twisting.

2、在使用扭力扳手時為防止扳手損壞和滑脫，應使拉力作用在開口較厚的一邊如此才能用上力。另外在使用扭力扳手時，要注意開口不能出現“八”字形，以免損壞螺母和扳手。

2. When using the torque wrench, in order to prevent the wrench from damage and slippage, the pulling force should act on the thicker side of the opening so as to use the force. In addition, when using the torque wrench, it should be noted that the opening should not appear "eight" shape, so as to avoid damaging the nut and wrench.

3、扭力扳手是按人手的力量來設計的，人手力量越大，扭力扳手在旋轉螺紋、螺母時的力量越大。如果遇到較緊的螺紋件，用扭力扳手也不能使其松動的話，切記不能用捶打工具錘擊扳手，以免損壞扳手，可以適當調整扳手的用力方向，找到合適的發力點。另外還要注意的是除了套筒扳手能套裝加力桿，其他扳手都不能套裝加力桿，扭力扳手也不能。遇到無法擰動的螺紋緊固件，不能胡亂給扭力扳手加裝加力桿，以防損壞扳手或螺紋連接件。

3. The torque wrench is designed according to the strength of human hands. The greater the strength of human hands, the greater the force of torque wrench when rotating threads and nuts. If a tight threaded part cannot be loosened with a torque wrench, remember not to hammer the wrench with a hammer tool, so as to avoid damaging the wrench. The force direction of the wrench can be adjusted appropriately to find the appropriate force point. In addition, it should be noted that in addition to the socket wrench can be equipped with an afterburner, no other wrench can be equipped with an afterburner, nor can a torque wrench. In case of screw thread fastener that cannot be turned, do not add force bar to torque wrench randomly to prevent damage to wrench or threaded connector.

4、扭力扳手一般都帶有預設扭矩?cái)?shù)值和聲響的裝置，當緊固件的擰緊扭矩達到預設數值時，扭力扳手能自動發出訊號“卡嗒”聲，同時伴有明顯的手感振動，這表示扭力扳手已經將緊固件松好。將扭力扳手從緊固件上取下后，扳手各相關零件能自動復位。

4. The torque wrench is usually equipped with a device with preset torque value and sound. When the tightening torque of the fastener reaches the preset value, the torque wrench can automatically send out a signal "click" sound, accompanied by obvious hand vibration, which indicates that the torque wrench has loosened the fastener. After the torque wrench is removed from the fastener, the relevant parts of the wrench can be reset automatically.

5、扭力扳手一般是用來旋轉螺栓或螺帽的，扳轉時應該使用拉力，推轉扳手極易發生危險。在使用時一定要注意這點。另外扭力扳手可以用來松緊螺栓，螺栓旋緊前應先將螺栓清潔并上潤滑油。

5. The torque wrench is generally used to rotate the bolt or nut. The pulling force should be used when turning, and the pushing wrench is easy to cause danger. This must be paid attention to when using. In addition, the torque wrench can be used to loosen the bolt, and the bolt should be cleaned and lubricated before tightening.

6、在使用扭力扳手旋緊螺栓時，應均勻使力，不得利用沖擊力。簡單來說就是不要用錘擊工具來錘擊扳手，使其在短時間內獲得沖擊力，從而帶動整只扳手旋轉，使扳手將螺栓旋緊，這種做法容易損壞扳手。

6. When using the torque wrench to tighten the bolt, the force should be evenly applied, and the impact force should not be used. In short, do not use hammering tools to hammer the wrench, so that it can obtain impact force in a short time, so as to drive the whole wrench to rotate, so that the wrench will tighten the bolt, which is easy to damage the wrench.

7、如果長期不用扭力扳手，建議把扭力扳手的調節標尺刻線退扭矩小數值處，這樣可以延長扳手的使用壽命。

7. If the torque wrench is not used for a long time, it is suggested that the scale marking of the torque wrench should be retreated to the small value of torque, so as to prolong the service life of the wrench.
